| CPU |
Intel® Socket LGA1700 for 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors*
Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
* Refer to www.asus.com for Intel® CPU support list.
** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types. |
| Bộ chip |
Intel® H610 Chipset |
| Bộ nhớ |
6 x DIMM, DDR4 3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory |
| Đồ họa |
Integrated Graphics Processor – Intel®HD Graphics support
Multi-VGA output support: DisplayPort/HDMI/DVI-D/D-Sub ports
– Supports DisplayPort with max. resolution of 4096×2160@60Hz
– Supports HDMI with max. resolution of 4096×2160@24Hz/ 2560×1600@60Hz
– Supports DVI-D with max. resolution of 1920×1200@60Hz
– Support D-sub port with max. resolution of 1920×1200@60Hz
* Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
** Supports max. 4K@60Hz as specified in DisplayPort 1.4.
*** Supports 4K@60Hz as specified in HDMI 2.1. |
| Khe cắm mở rộng |
1 x PCI Express 4.0/3.0 x16 slot (at x16 mode)
2 x PCI Express 3.0 x16 slot (at x1 mode)
1 x PCI slot |
| Lưu trữ |
Intel® H610 Chipset
– 1 x M.2 2280, 2260, 2242 (Gen3 x4 PCIE mode)
– 4 x Serial ATA 6.0 Gb/s connectors |
| Ethernet |
1 x Gigabit LAN |
| USB |
2 x USB 3.2 Gen2 ports (1A1C at rear panel)
2 x USB 3.2 Gen1 ports (2 x Type-A at mid-board)
8 x USB 2.0 ports (6 ports at mid-board, 2 ports at rear panel) |
| Âm thanh |
Realtek ALC897
* Use a chassis with HD audio module in the front panel to support an 8-channel audio output. |
| Cổng I/O mặt sau |
1 x PS/2 keyboard/mouse combo port
1 x DisplayPort
1 x HDMI port
1 x DVI-D port
1 x D-Sub Port
1 x LAN (RJ-45) port
2 x USB 3.2 Gen2 ports (1A1C)
2 x USB 2.0 ports
1 x COM port
3 Audio jacks support 8 channel audio port |
| Đầu nối I/O nội bộ |
1 x USB 3.2(Gen1) connector supports additional 2 USB 3.2 Gen1 ports
3 x USB 2.0 connectors support additional 6 USB 2.0 ports
4 x SATA 6Gb/s connectors
1 x CPU fan connector (PWM mode only)
1 x Chassis fan connector (PWM mode only)
1 x System panel connector
1 x Front panel audio connector (AAFP)
1 x LPT connector
1 x 24-pin ATX Power connector
1 x 8-pin ATX 12V Power connector
1 x COM connector
1 x S/PDIF out connector
1 x speaker connector
1 x Clear CMOS connector
1 x Chassis intrusion header
1 x COM debug header
1 x SPI_TPM header |
| Các tính năng đặc biệt |
ASUS 5X PROTECTION III
– ASUS SafeSlot Core: Fortified PCIe Slot prevents damage
– ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges
– ASUS Overvoltage Protection: World-class circuit-protecting power design
– ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability
– ASUS DIGI+ VRM – 3 Phase digital power design
Superb Performance
ASUS OptiMem
– Improved DDR4 stability
ASUS EPU
– EPU
UEFI BIOS
– Most advanced options with fast response time
IT Management software supported
-ASUS Control Center Express(ACCE)
EZ DIY
UEFI BIOS EZ Mode
– featuring friendly graphics user interface
– ASUS CrashFree BIOS 3
– ASUS EZ Flash 3
ASUS Q-Design
– ASUS Q-DIMM
– ASUS Q-Slot
ASUS Quiet Thermal SolutionQuiet Thermal Design:
– Stylish Fanless Design: PCH heatsink solution
– ASUS Fan Xpert |
| BIOS |
128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information |
| Khả năng quản lý |
WOL by PME, PXE |
| Phụ kiện đi kèm |
2 x Serial SATA 6.0Gb/s cables
1 x I/O shield
1 x M.2 screw pakage |
| Hệ điều hành |
Windows® 11 64-bit, Windows® 10 64-bit |
| Form Factor |
Micro ATX Form |
